USB DACs on Desktop Systems: Power, Ground Loops and Hum

Buy the DAC for its power arrangement rather than its converter chip, and most desktop noise problems disappear before they start. The converter is rarely the limiting factor in a computer-based system; the USB link and the shared ground are.

Why the USB link causes noise

USB carries both data and power on the same cable, and the ground conductor is shared with the computer. Any current flowing on that ground path develops a small voltage that appears in series with the audio signal.

Processor activity modulates that current, which is why the resulting noise changes when the machine is busy and disappears when it is idle.

The symptom is usually a whine or a series of clicks that track the cursor, a scroll or a file copy, rather than a steady hiss.

Power arrangements and what they fix

A bus-powered DAC draws all its current from the computer. It is simple and portable, and it inherits every problem on the USB ground.

A self-powered DAC with its own supply isolates the analogue section from the computer’s power rails. That removes most computer noise, though a ground loop on the signal path can remain.

A DAC with galvanic isolation on the USB input breaks the ground connection entirely. That is the most complete fix and the one to look for when a system hums no matter what else changes.

Diagnosing a hum in five minutes

Disconnect the source and listen. If the hum is still present, it comes from the amplifier or from the mains.

Reconnect the source with a completely different computer, such as a laptop running on battery. If the hum stops, the original computer’s ground is the cause.

Then connect both devices to the same power strip. If the hum reduces noticeably, a ground loop between two mains points was the problem.

Finally, try an optical or a transformer-isolated connection. If that removes the remainder, the fix is isolation rather than a new converter.

Volume control placement

Where the volume control sits in the chain affects both noise and resolution. A digital volume control has to leave enough bits after attenuation to preserve low-level detail.

Reducing the level digitally by 40 dB in a 16-bit stream leaves very little resolution for quiet passages, which is why many systems sound thin when the digital volume is set low.

The usual compromise is to keep the digital control near maximum and apply attenuation in the analogue domain, or to use a player that operates at higher internal precision.

Sample rate and driver behaviour

Fixed sample rate operation resamples everything to one value, which adds a conversion step that some listeners find audible on high-resolution material.

Automatic sample rate switching avoids that step, and it is the reason to prefer drivers that follow the file rather than forcing a fixed rate.

Asynchronous USB, where the DAC controls the timing rather than the computer, reduces jitter from the host. Most current converters use it by default, and it is worth checking rather than assuming.

Cables and connectors

A USB cable either works or does not. Where a system is noisy, changing the cable rarely helps unless the original was out of specification or unusually long.

Keep the analogue output cables short and route them away from mains leads and monitors. A shielded cable running alongside a power supply can pick up hum that no amount of converter upgrading will remove.

Balanced outputs are worth using where a long cable run is unavoidable, because the common-mode rejection removes interference that a single-ended cable would carry into the amplifier.

A sensible desktop arrangement

Use a self-powered or isolated DAC, connect everything to one power strip, keep the digital volume near maximum, and route analogue cables away from power leads.

Then judge the converter by listening, not by the chip name. In a typical desktop system the differences between competent converters are smaller than the differences caused by the noise and ground arrangements around them.

What to ignore

Ignore claims about converter chips without measurements, and ignore cable upgrades as a cure for a hum that survives the same-power-strip test.

Ignore bit-depth marketing where the source material is 16-bit. The extra resolution is not present in the recording.
